Description:

Features:

• Featuring a 52” ENVY™ ELITE CUTTING SYSTEM fabricated deck that’s 5½” deep and made of 10-gauge steel
• Powerful 23 hp/726 cc Kawasaki® FR691V engine
• Fully tubular steel frame, Self-adjusting belt technology, High-Back Padded Seat and armrests, Foot-operated deck lift

Specifications:

General

• Model Number: 991159
• Engine: Kawasaki® FR691V
• Displacement: 726 cc
• Horsepower: 23 hp
• Fuel Capacity: 5.1 gal (19.3 l)

Cutting Deck

• Cutting Width: 52 in (132.1 cm)
• Cutting Height Range: 1.5 – 5 in (3.8 – 12.7 cm)
• Cutting Positions: 15
• Spindles: Forged Aluminum
• Deck Engagement: Electric Warner
• Deck Lift: Foot Operated
• Deck Lift Assist: Standard
• Transport Lock: Standard

Drive System

• Transmission: Hydro-Gear® ZT-3100®
• Forward Speed: Up to 8 mph (12.9 kph)
• Reverse Speed: Up to 4 mph (6.4 kph)

Dimensions

• Weight: 816 lb (370.1 kg)
• Length: 79 in (200.7 cm)
• Width (Chute Up): 56.2 in (142.7 cm)
• Width (Chute Down): 67.3 in (170.9 cm)

Warranty

• Coverage: 4 years or 500 hours

Features

• Lights: Available as accessory
• Seat Isolation: Available as accessory
• Floor Mat / Deck Storage / Auxiliary Power: Not applicable
