Description:

Put your best foot forward with the power and performance of the PRO-TURN 100.

Every inch is of value on the PRO-TURN 100. Packed with Gravely brand’s time-tested features, this hard-working mower stands up to your toughest jobs.

Specifications:

Engine

• Brand: Kawasaki® FX691V
• Horsepower: 22 hp
• Displacement: 726 cc (44.3 cu in)
• Fuel Type: Gas
• Fuel Capacity: 10 gal (37.9 L)

Drive System

• Transmission Brand: Hydro-Gear® ZT-3400
• Type: Hydrostatic
• Brakes: Lever-activated parking
• Drive Position: Sit-on
• Forward Speed: Up to 10 mph (16.1 km/h)
• Reverse Speed: Up to 5 mph (8 km/h)

Wheels

• Front Wheels: 13 x 6.5 in
• Rear Wheels: 23 x 10.5 in

Electrical

• Battery Capacity: 300 CCA
• Battery Type: Lead Acid (Maintenance Free)
• Battery Size: U1

Deck

• Deck Size: 52 in (132.1 cm)
• Deck Type: Fabricated X-Factor® II
• Deck Thickness: 7-gauge steel
• Discharge Type: Side
• Cutting Width: 52 in (132.1 cm)
• Cutting Height Range: 1 – 5 in (2.5 – 12.7 cm)
• Coverage/Hour: Up to 5.2 acres (2.1 hectares)

Dimensions

• Weight: 1079 lb
• Length: 78.5 in (199.4 cm)
• Width (Chute Up): 55.5 in (141 cm)
• Width (Chute Down): 67.5 in (171.5 cm)
