Description:

Built for big jobs, the ZT XL has been redesigned with vibration isolators and a high-back seat to combine professional cut quality and comfort. Out-maneuver any obstacle with more deck sizes to meet your demands.

Specification:

Model Number: 918015

Power Train:

• Engine: Kawasaki® FR691V
• Horsepower: 23 HP
• Engine Displacement: 44.3 in³ / 726 cc
• Fuel System: Gas
• Fuel Capacity: 3.5 gal / 13.2 L
• Drive System: Hydro-Gear® ZT-2800® Transaxles
• Transmission Type: Hydrostatic
• Brake Type: Integrated Parking Brake
• Driver Position: Sit
• Ground Speed Forward: 7 mph / 11.3 kph
• Ground Speed Reverse: 3 mph / 4.8 kph

Wheels:

• Front Wheels: 11.0 x 6.0 in - 5.0 in (27.9 x 15.2 cm - 27.9 cm)
• Rear Wheels: 20.0 x 10.0 in - 8.0 in (50.8 x 25.4 cm - 20.3 cm)

Electric:

• Battery Capacity: 190 CCA
• Number of Batteries: 1
• Battery Voltage: 12 V
• Battery Type: AGM
• Battery Size: U1 Compatible

Deck:

• Deck Size: 52 in / 132.1 cm
• Coverage Hour: 3.6 acres / 1.5 hectares
• Spindle Type: Mechanical
• Deck Material: 11 ga
• Deck Construction: Fabricated X-Factor®
• Discharge Configuration: Side
• Cutting Height Minimum: 1.5 in / 3.8 cm
• Cutting Height Maximum: 4.5 in / 11.4 cm
• Cutting Width: 52 in / 132.1 cm

Dimensions:

• Weight (Assembled): 705 lb
• Length: 74.5 in / 189.2 cm
• Width (Chute Up): 55.6 in / 141.2 cm
• Width (Chute Down): 66.7 in / 169.4 cm
