Description:

Specifications:

Engine

• Cylinder Displacement: 5.66 cu.in (approx. 92.8 cm³)
• Output Shaft Power: 7.6 hp
• Chain Speed at Max Power: 75.5 ft/s
• Exhaust Emissions (CO₂ EU V): 736 g/kWh

Cutting Equipment

• Bar Length: 24 in (60 cm)
• Recommended Bar Length (Min–Max): 18 in – 36 in
• Pitch: 3/8"
• Gauge: 1.5 mm (.058")
• Chain Type: X-Cut C85
• Bar Type: X-Tough RSN (Replaceable Sprocket Nose)

Dimensions & Weight

• Weight (Excl. Cutting Equipment): 16.3 lbs (7.4 kg)

Sound and Noise

• Sound Pressure Level at Operator’s Ear: 112 dB(A)
• Sound Power Level, Guaranteed (LWA): 119 dB(A)

Vibration

• Front Handle Vibration Level (ahv, eq): 6.7 m/s²
• Rear Handle Vibration Level (ahv, eq): 5.9 m/s²
