LS Tractor MT226E Compact Tractors

LS Tractor MT226E Compact Tractors

Call For Price
SKU: LS Tractor MT226E Compact Tractors-MT226
Categories : LS Tractor

Description:

Features:

  • Redesigned air conditioning and roof configuration, providing additional head space and increased forward visibility
  • Much improved seat comfortability
  • Factory A/C cab available in a 25HP tractor
  • New hood design (LS Family look), Grill open space plus 20%
  • LED head Lamp
  • 1 Inch large tire size and four different tire options
  • Larger lifting capacity, loader lifting capacity -> New MT226E (LL3301/2) 1,965 lbs. New MT2E & MT2(LL3303) 2,506 lbs.
  • Workability, 4-point mount structure as well -> digging depth of 97.2” and bucket digging force of 3,663 lbs.
  • TF-LCD instrument panel providing various information like, regen time, oil change interval, etc.
  • E/G RPM interlocking switch (STD). When working at low RPM, instantaneous RPM can be increased by simply manipulating the toggle switch to momentarily increase loader speed/lift (option).

Specifications:

Engine

  • Type: 3-Cylinder, Liquid-cooled, Diesel (Natural Aspirated, Indirect Injection)
  • Model (Tier 4): MHI
  • Gross Engine HP: 24.6 HP
  • PTO HP: 19.2 HP
  • Rated Speed: 2,500 RPM
  • Displacement: 80.4 cu. in
  • Fuel Tank Capacity: 10.6 gallons
  • Alternator: 12V, 50 Amps

Drive Train

  • Transmission Type: Synchro Shuttle
  • Speeds: 12 Forward / 12 Reverse
  • Brakes: Wet, Multi-disc
  • Steering: Hydrostatic Power Steering

PTO (Power Take-Off)

  • Type: Independent
  • Rear RPM: 540 (Standard)

Hydraulics

  • Control System: Position Control
  • Implement Pump Flow: 7.9 gpm
  • Steering Pump Flow: 4.6 gpm
  • Total Hydraulic Flow: 12.5 gpm
  • 3-Point Hitch Category: CAT I
  • Lift Capacity at Hitch End: 1,808 lbs
  • Remote Valves: Optional

Dimensions

  • Overall Length: 119 in
  • Overall Width (with tires): 66 in
  • Wheelbase: 66 in
  • Height to Top: 95 in

Tire Sizes

  • Ag Tires (Front / Rear): 7 – 14 / 11.2 – 24
  • Industrial (Front / Rear): 27x8.50-15 / 43x16.00-20
  • VT (Front / Rear): 27x8.50-15 / 43x16.00-20
  • Turf (Front / Rear): 25x8.50-14 / 41x14.00-20

Weight

  • Without Ballast: 2,985 lbs

Width Weight Height Length
0 Inch 2985 Pounds 0 Inch 0 Inch
