Description:

The MT3E Series provides a variety of horsepower ratings and transmissions to accommodate any customers needs. Those customers requiring value and power will find plenty of both in this robust series of LS tractor.

Specifications:

Engine

• Type: Vertical Water Cooled 4 Cycle Diesel Engine
• Model (Tier 4): L3C19-T
• Emissions: EPA & CARB Tier 4F, EU Stage IIIB
• Gross Horsepower: 45 HP (33.5 HP)
• PTO Horsepower: 36 – 38.2 HP
• Rated Speed: 2,600 RPM
• Displacement: 114.7 cu. in.
• Fuel Tank Capacity: 13.7 gallons

Drive Train

• Transmission: HST (Hydrostatic Transmission)
• Number of Speeds: 3 Ranges
• Brakes: Wet, Multi-Disc
• Steering: Hydrostatic Power Steering

PTO (Power Take-Off)

• Type: Independent
• Rear RPM: 540

Hydraulic System

• Control System: Position
• Implement Pump Flow: 8.2 GPM
• Steering Pump Flow: 4.8 GPM
• Total Flow: 13.0 GPM
• Category (3 pt hitch): CAT 1
• Hitch Lift Capacity: 2,910 lbs
• Remote Valves: 2 pairs (Front), 1/2 pairs (Rear, Optional)
• Steering: Hydrostatic Power Steering

Dimensions

• Overall Length (Bumper to Link): 125 in.
• Wheelbase: 68 in.
• Overall Width with Tires: 74.8 in.
• Height to Top of ROPS: 100 in.

Tire Size Options

• Ag Tires:
• Front: 9.5-16
• Rear: 14.9-24
• Industrial Tires:
• Front: 10.0-16.5
• Rear: 17.5L-24
• Turf Tires:
• Front: 29 x 12.50-15
• Rear: 44 x 18.00-20
• Narrow Ag Tires:
• Front: 7.0 – 14
• Rear: 9.5 – 24

Weight

• Total Weight (Without Ballast): 3,724 lbs (E) – 3,750 lbs (HE)
