Specifications:

The MT4 features a variety of configurations enabling you to find the exact configuration you need. A ROPS and Cab version are available with highly featured operator platforms/cabs. The ergonomic design provides all-day comfort, as the robust frame provides high-capacity front loader and three point lift.

Specifications:

ENGINE

• Type: Vertical Water-Cooled 4-Cycle Diesel Engine
• Model (Tier 4): L4C25-T
• Engine HP (Gross): 58 HP
• PTO HP: 51.2 HP
• Rated Speed: 2,500 RPM
• Displacement: 152.8 cu in
• Fuel Tank Capacity: 21.1 gal
• Alternator: 12V – 70A

DRIVE TRAIN

• Transmission: Synchro Shuttle
• Number of Speeds: F16 x R16
• Brakes: Wet, Multi Disc
• Steering: Hydrostatic Power Steering

PTO

• Type: Independent
• Rear RPM: 540

HYDRAULIC SYSTEM

• Control System: Position/Draft
• Implement Pump Flow: 9.9 gpm
• Steering Pump Flow: 4.6 gpm
• Total Flow: 14.5 gpm
• Category (3-Point Hitch): CAT II
• Hitch Lift Capacity: 4,079 lbs
• Remote Valves: 2 pairs (Front), 2 pairs (Rear) (1 detent, 1 standard)

DIMENSIONS

• Overall Length with 3-Point Hitch: 138.6 in
• Wheelbase: 80.3 in
• Minimum Overall Width with Ag Tires: 70 in
• Height to Top of Cab with Ag Tires: 103 in

TIRE SIZE

• Agricultural Tires (Front/Rear): 9.5 – 20 / 16.9 – 24
• Industrial Tires (Front/Rear): 10.5/80 – 18 / 19.5L – 24

WEIGHT

• Total Weight without Ballast: 4,674 lbs
