Description:

Features:

• 24F x 24R Power Shuttle​
• Standard Air Suspension Seat ​
• Standard Electric Engaged Independent PTO​
• Standard Instructor Seat​
• Standard Interior Power Source​
• Optional Third Rear Remote​

Specifications:

Engine

• Type: 4-Cylinder, CRDI, Water-cooled
• Model: F34 (Tier 4)
• Gross Horsepower: 73.7 HP
• PTO Horsepower: 65.6 HP
• Rated Speed: 2,200 RPM
• Displacement: 206.7 cu. in
• Fuel Tank Capacity: 30.4 gal

Drive Train

• Transmission: Power Shuttle
• Speeds: 24 Forward / 24 Reverse
• Brakes: Wet, Multi-disc
• Forward Speed Range: 0.9 – 20.8 mph

PTO

• Type: Independent
• Speeds: 540 / 750 / 1,000 RPM

Hydraulic System

• Control: Position / Draft
• Implement Pump Flow: 15.7 gpm
• Steering Pump Flow: 6.5 gpm
• Total Hydraulic Flow: 22.2 gpm
• 3-Point Hitch Category: CAT II
• Lift Capacity (at hitch end): 7,275 lbs
• Remote Valves:
• Front: 3 pairs
• Rear: 2 pairs

Dimensions

• Length (Frame to Link): 152.2 in
• Wheelbase: 90 in
• Width (Min. with tires): 78.7 in
• Height (to top): 105 in

Tires

• R14 Industrial: Front 320/85R24, Rear 460/85R30
• Ag (Agricultural): Front 11.2-24, Rear 16.9-30

Weight

• Without Ballast: 7,827 lbs
